FireStudio
FireStudio
SKU: FIRESTUDIO
FireStudio
Overview
The PreSonus FireStudio is the next generation in FireWire recording systems from PreSonus. Based on the award-winning Firepod, the FireStudio combines superior analog circuit design with new advanced platform technology to deliver enhanced performance for music recording and creation.
The FireStudio is a 26x26 24-bit/96k professional recording system combining eight XMAX Class A PreSonus microphone preamplifiers, up to sixteen channels of optical ADAT input / output, S/PDIF and MIDI input / output, along with the Control Console - a 36x36x18 zero latency mixer/router.
The FireStudio is bundled with PreSonus Studio One Artist, our groundbreaking music creation program, and over 4 GB of virtual instruments, plug-ins, loops, and samples to get you started making music immediately.
Overview
Features
- 8 dual-purpose front-panel channel inputs, each with high-headroom Class A XMAX™ mic preamplifiers
- 6 mic/line inputs
- 2 mic/instrument inputs
- Individual channel-trim controls with -20 to +20 dBV line / 0 to 60 dBu mic range and clip LED
- 48V phantom power for condenser microphones (Inputs 1-4 and 5-8, bank-switchable)
- Headphone jack with level control
- Main-output gain control
- Power/Sync LED (indicates unit is synced to word clock)
- Daisy-chain multiple FireStudios or other FireStudio-family products to create a large, custom system
- Remote controllable via optional Monitor Station Remote (MSR)
- Studio One Artist™ digital audio workstation software included
- 2 FireWire 400 ports
- S/PDIF digital input/output
- 16 channels of optical ADAT I/O @ 44.1/48 kHz (8 ch. @ 96 kHz via dual SMUX)
- 6 combination XLR/¼” mic/line-level inputs
- 2 combination XLR/¼” mic/instrument (high impedance) inputs
- Unbalanced stereo line-level inputs (RCA)
- 2 stereo ¼” inserts
- 2 ¼” main (L/R) analog outputs
- 8 ¼” general-purpose outputs
- MIDI in/out
- Word-clock in/out (BNC)
- Remote-control input
- ¼” headphone output
- 24-bit resolution, up to 96 kHz sampling rate
- High-definition analog-to-digital converters (118 dB dynamic range)
- DICE II chipset for ultra-efficient data transfer
- JetPLL™ jitter-elimination technology
- Zero-latency monitoring via 36x18 DSP matrix mixer/router
- Mac®- and Windows®-compatible, including Mac OS X 10.6 Snow Leopard and Windows 7
- Supports ASIO, Core Audio, Direct Sound (Windows XP), Windows Audio Session API (Windows Vista and Windows 7)
- 1U 19” rack-mountable, rugged steel chassis
- Sealed, detented, metal rotary controls
- Internal power supply with standard IEC power cord
- Studio One® Artist
- PreSonus’ revolutionary new digital audio workstation, with unlimited track count and 6+ GB of 3rd-party resources. With Studio One's Nimbit® extension, you can immediately start selling your music.
- Universal Control control-panel application for Mac® OS X and Windows®
