AIR XD 15 2-way 1 x 15” Active Extended Definition Loudspeaker

AIR XD 15 2-way 1 x 15” Active Extended Definition Loudspeaker

SKU: 2779100108
¥104,100
¥104,100 ¥104,100
Sale Sold out
Powerful and portable, the PreSonus AIR XD 15 features a 15-inch woofer, 1.35-inch tweeter, and over 1,500W of Class D power with TWS Bluetooth stereo—perfect for mobile gigs or permanent installs in a compact, lightweight design.
View full details

AIR XD 15 2-way 1 x 15” Active Extended Definition Loudspeaker

¥104,100
¥104,100 ¥104,100
Sale Sold out

      Overview

      • The PreSonus AIR XD 15 is a full-range active loudspeaker designed for professional use, delivering extended-definition sound, high SPL, and precise tonal balance for any application. Its custom 15-inch low-frequency driver features an enlarged 2.56” voice coil for efficient power handling and extended low-end response down to 40 Hz, producing tight, dynamic bass with minimal distortion. The 1.35” high-frequency driver uses a PEEK diaphragm, offering exceptional stiffness, wear resistance, and high-temperature tolerance, resulting in clear, detailed, and ultra-responsive highs even under prolonged, high-output operation.
      • Powered by 1,500W of efficient Class D amplification, the AIR XD 15 can reach up to 134 dB SPL while maintaining clarity and headroom. Onboard DSP presets, ±10 dB EQ, and performance tuning modes allow quick adjustment for speech, music playback, FOH, or monitor use. A full-color 2.6” LCD provides intuitive metering, system control, and rapid access to all settings.
      • Built-in Bluetooth with TWS Bridge Mode enables effortless wireless stereo pairing, making it ideal for mobile DJs, corporate events, and fast setups. The integrated mixer includes combo mic/line and aux inputs, allowing seamless connectivity and versatile signal routing. Rugged enclosures with ergonomic handles and multiple mounting options make the AIR XD 15 as portable as it is powerful, whether flown, pole-mounted, ground-stacked, or used as a floor monitor.

      Overview

      Features

      • Custom 15-inch low-frequency driver with enlarged voice coil for extended low-end response down to 40 Hz
      • 1.35” High-frequency compression driver with PEEK diaphragm for clear, detailed, and durable highs
      • 1,500W Class D bi-amplification for clean, efficient power and up to 134 dB SPL
      • Onboard DSP with performance presets, ±10 dB EQ, and tuning modes for speech, music, FOH, or monitor use
      • Full-color 2.6" LCD for fast, intuitive metering and system control
      • Built-in Bluetooth with TWS Bridge Mode for true wireless stereo pairing
      • Integrated 3-channel mixer with combo mic/line and aux inputs for flexible connectivity
      • 90˚ horizontal dispersion and 60˚ vertical dispersion
      • Frequency Response: 47 Hz to 20 kHz (-3 dB), 40 Hz to 20 kHz (-10 dB)
      • Rugged, portable enclosure with ergonomic handles and multiple mounting options: flown, pole-mounted, ground-stacked, or floor wedge

      Downloads

      Documentation

    • Owner's Manual - English
    • PreSonus Hardware Products 6-Year Limited Transferrable Warranty 2023 (Multilingual)

      • Specs

      Electronics

      Auxiliary Input

      1/8 in (3.5 mm) Stereo

      Bluetooth

      Bluetooth® V5.0

      Channels

      Three

      Connectivity

      Bluetooth

      Inputs

      Four - (2 x XLR/TRS Mic/Line Combo, 1 x 1/8” TRS Stereo, Bluetooth Stereo)

      Line Out

      One - 1 x XLR Mix Out

      Power Consumption

      3.3A (230V-50 Hz), 6.6A (120V)

      VoltageRequirements

      100-240 VAC, 50-60 Hz

      General

      Amplifier Type

      Class-D

      Color

      Black

      Product Name

      AIR XD 15 2-Way Active Sound-Reinforcement Loudspeaker

      Series

      AIR

      Hardware

      Audio Controls

      Gain, Volume, Hi/Lo EQ

      Cabinet Material

      H-PP Molded

      Cooling

      Passive radiator

      Grille Material

      1.2 mm Steel

      HF Powere

      468W

      HF Transducers

      1.35” Compression

      Handle

      1 Top, 1 Side

      LF Power

      1060W

      LF Transducers

      15” (2.56” Voice Coil)

      Pole Socket

      Dual Position (0˚, 7.5˚)

      Inputs

      Line Input Connection Type

      XLR/TRS Mic/Line Combo

      Line Inputs Impedance

      30K ohm

      Line Inputs Maximum Level

      +14dBu

      Microphone Preamp Input Impedance

      30K ohm

      Measurements

      Product Depth

      15.8" (40.2 cm)

      Product Height

      27.9" (70.9 cm)

      Product Height/Length

      27.9" (70.9 cm)

      Product Weight

      51.3 lbs (23.1 kg)

      Product Width

      16.9" (42.9 cm)

      Miscellaneous

      DSP Features

      Speaker modes, Location, Bass, Treble

      Power Cable

      IEC

      Protections

      Output limiter

      Suspension

      M10 Suspension Points, Flypoints: 2 Top, 1 Back

      Output

      Line Outputs Connection Type

      XLR Male, Balanced

      Performance

      Peak SPL

      134 dB

      Total Power Output

      1500 Watts

      Speakers

      Coverage Pattern

      90 degree (H) x 60 degree (V)

      Crossover Frequency

      1.6 kHz

      Speaker Type

      Active 2-Way

      Total Impedance

      NA
